: The Dialog element – HTML: HyperText Markup Language

adminDecember 6, 2024

0 10 4 minutes read

s are set to display: none; when hidden and display: block; when shown, as well as being removed from / added to the top layer and the accessibility tree. Therefore, for elements to be animated the display property needs to be animatable. Supporting browsers animate display with a variation on the discrete animation type. Specifically, the browser will flip between none and another value of display so that the animated content is shown for the entire animation duration.

So for example:

When animating display from none to block (or another visible display value), the value will flip to block at 0% of the animation duration so it is visible throughout.
When animating display from block (or another visible display value) to none, the value will flip to none at 100% of the animation duration so it is visible throughout.

Transitioning dialog elements

When animating

s with CSS transitions, the following features are required:

@starting-style at-rule: Provides a set of starting values for properties set on the
that you want to transition from every time it is opened. This is needed to avoid unexpected behavior. By default, CSS transitions only occur when a property changes from one value to another on a visible element; they are not triggered on elements’ first style updates, or when the display type changes from none to another type.
display property: Add display to the transitions list so that the
will remain as display: block (or another visible display value set on the dialog’s open state) for the duration of the transition, ensuring the other transitions are visible.
overlay property: Include overlay in the transitions list to ensure the removal of the
from the top layer is deferred until the transition completes, again ensuring the transition is visible.
transition-behavior property: Set transition-behavior: allow-discrete on the display and overlay transitions (or on the transition shorthand) to enable discrete transitions on these two properties that are not by default animatable.

Here is a quick example to show what this might look like.

HTML

The HTML contains a

element, plus a button to show the dialog. Additionally, the element contains another button to close itself.

html


  Content here

CSS

In the CSS, we include a @starting-style block that defines the transition starting styles for the opacity and transform properties, transition end styles on the dialog[open] state, and default styles on the default dialog state to transition back to once the

has appeared. Note how the ‘s transition list includes not only these properties, but also the display and overlay properties, each with allow-discrete set on them.

We also set a starting style value for the background-color property on the ::backdrop that appears behind the

when it opens, to provide a nice darkening animation. The dialog[open]::backdrop selector selects only the backdrops of elements when the dialog is open.

css

/*   Open state of the dialog  */
dialog[open] {
  opacity: 1;
  transform: scaleY(1);
}

/*   Closed state of the dialog   */
dialog {
  opacity: 0;
  transform: scaleY(0);
  transition:
    opacity 0.7s ease-out,
    transform 0.7s ease-out,
    overlay 0.7s ease-out allow-discrete,
    display 0.7s ease-out allow-discrete;
  /* Equivalent to
  transition: all 0.7s allow-discrete; */
}

/*   Before-open state  */
/* Needs to be after the previous dialog[open] rule to take effect,
    as the specificity is the same */
@starting-style {
  dialog[open] {
    opacity: 0;
    transform: scaleY(0);
  }
}

/* Transition the :backdrop when the dialog modal is promoted to the top layer */
dialog::backdrop {
  background-color: rgb(0 0 0 / 0%);
  transition:
    display 0.7s allow-discrete,
    overlay 0.7s allow-discrete,
    background-color 0.7s;
  /* Equivalent to
  transition: all 0.7s allow-discrete; */
}

dialog[open]::backdrop {
  background-color: rgb(0 0 0 / 25%);
}

/* This starting-style rule cannot be nested inside the above selector
because the nesting selector cannot represent pseudo-elements. */

@starting-style {
  dialog[open]::backdrop {
    background-color: rgb(0 0 0 / 0%);
  }
}

JavaScript

The JavaScript adds event handlers to the show and close buttons causing them to show and close the

when they are clicked:

const dialogElem = document.getElementById("dialog");
const showBtn = document.querySelector(".show");
const closeBtn = document.querySelector(".close");

showBtn.addEventListener("click", () => {
  dialogElem.showModal();
});

closeBtn.addEventListener("click", () => {
  dialogElem.close();
});

Result

The code renders as follows:

Note: Because

s change from display: none to display: block each time they are shown, the transitions from its @starting-style styles to its dialog[open] styles every time the entry transition occurs. When the closes, it transitions from its dialog[open] state to the default dialog state.

It is possible for the style transition on entry and exit to be different in such cases. See our Demonstration of when starting styles are used example for a proof of this.

dialog keyframe animations

When animating a

with CSS keyframe animations, there are some differences to note from transitions:

You don’t provide a @starting-style.
You include the display value in a keyframe; this will be the display value for the entirety of the animation, or until another non-none display value is encountered.
You don’t need to explicitly enable discrete animations; there is no equivalent to allow-discrete inside keyframes.
You don’t need to set overlay inside keyframes either; the display animation handles the animation of the from shown to hidden.

Let’s have a look at an example so you can see what this looks like.

HTML

First, the HTML contains a

element, plus a button to show the dialog. Additionally, the element contains another button to close itself.

html


  Content here

CSS

The CSS defines keyframes to animate between the closed and shown states of the

, plus the fade-in animation for the ‘s backdrop. The animations include animating display to make sure the actual visible animation effects remain visible for the whole duration. Note that it wasn’t possible to animate the backdrop fade out — the backdrop is immediately removed from the DOM when the is closed, so there is nothing to animate.

css

dialog {
  animation: fade-out 0.7s ease-out;
}

dialog[open] {
  animation: fade-in 0.7s ease-out;
}

dialog[open]::backdrop {
  animation: backdrop-fade-in 0.7s ease-out forwards;
}

/* Animation keyframes */

@keyframes fade-in {
  0% {
    opacity: 0;
    transform: scaleY(0);
    display: none;
  }

  100% {
    opacity: 1;
    transform: scaleY(1);
    display: block;
  }
}

@keyframes fade-out {
  0% {
    opacity: 1;
    transform: scaleY(1);
    display: block;
  }

  100% {
    opacity: 0;
    transform: scaleY(0);
    display: none;
  }
}

@keyframes backdrop-fade-in {
  0% {
    background-color: rgb(0 0 0 / 0%);
  }

  100% {
    background-color: rgb(0 0 0 / 25%);
  }
}

body,
button {
  font-family: system-ui;
}

JavaScript

Finally, the JavaScript adds event handlers to the buttons to enable showing and closing the

const dialogElem = document.getElementById("dialog");
const showBtn = document.querySelector(".show");
const closeBtn = document.querySelector(".close");

showBtn.addEventListener("click", () => {
  dialogElem.showModal();
});

closeBtn.addEventListener("click", () => {
  dialogElem.close();
});

Result

The code renders as follows:
